In January 2019 photo of Pakistan-future-stealth-aircraft (Project AZM) was leaked. The photo accidentally exposed the proposed model of three single-head stealth fighters named as JF-20, JF-17, and JF-17.6.
The Conceptual design of Pakistan-future-stealth-aircraft was also spotted on the tail of PAF C-130 during Royal International Air Tattoo (RIAT) 2019.
— ? (@rabiyahashme) July 27, 2019
Now according to the Pakistan Ministry of Defence Production’s (MoDP) yearbook for 2017-2018, the Aviation Research, Innovation and Development (AvRID) Secretariat completed the first of four “conceptual design phase” cycles for the Pakistan Air Force’s (PAF) fifth-generation fighter aircraft (FGFA) program.
The MoDP yearbook states:
“The first cycle of the conceptual design phase has been completed. The first configuration that was designed based on the challenging performance requirements of PAF will go through three more cycles within the conceptual design using higher fidelity analysis tools and codes.”
The FGFA is the centerpiece of Project Azm, the PAF’s vision for developing a turnkey aviation industrial base within Pakistan to support the country’s defence as well as civilian and commercial aviation needs.
The PAF formally initiated Project Azm in July 2017 with the objective of developing an FGFA, a medium-altitude and long-endurance (MALE) unmanned aerial vehicle (UAV), new munitions, and other projects.
When it announced Project Azm, the then Chief of Air Staff (CAS), Air Chief Marshal (ACM) Sohail Aman, had stated that the design work of the MALE UAV was in its “final stages.” The 2017-2018 MoDP yearbook stated that the scheduled deadline for the MALE UAV’s maiden flight was June 2019.
Since the MoDP yearbooks cover issues completed over 12-18 months prior to publication, it would mean that the MALE UAV either flew or was delayed and that the FGFA is well into its subsequent design work.
In terms of the FGFA, in a recent interview with the PAF Chief of Air Staff (CAS), Air Chief Marshal Mujahid Anwar Khan, stated that he does not expect the FGFA to become operational for “another decade.”
The CAS had also revealed the current Air Staff Requirements (ASR) of the FGFA, i.e., a “twin-engine single-seater, boasting the likes of super-cruise and laser weapons (directed energy weapons).”
Thus, the FGFA is not only a clean-sheet design but currently slated as a medium-to-heavyweight, high-performance jet.
This design configuration indicates that the PAF intends to produce a platform capable of heavier payloads and range than the JF-17.
In other words, a platform optimized for offensive counter-air (OCA), maritime, and deep-strike platforms, i.e., a direct successor of both the F-16A/B Block-15s and the Mirage III/5…
